Heavy Duty Air Cleaner

Deluxe 2-stage air cleaner protects engine from contaminants and prolongs product life.

Engine Temperature Alarm

An audible alarm and indicator light notify the operator if the engine temperature exceeds an acceptable level.

Patented Adjustable Baffle

Allows operator to achieve maximum cutting performance by fine-tuning deck to conquer changing conditions, unique job sites or different times of the season. In extreme conditions, the baffle can be opened in order to conserve power and achieve faster mowing speeds. In less demanding conditions, the baffle can be closed to yield micro-sized particles and maximize discharge velocity.

A flat, crisp cut with precision blades.

1/4" thick precision blades resist flexing to provide a flat, crisp cut. High-strength, heat-treated alloy steel survives impacts and provides resistance to the rapid wear commonly associated with abrasive conditions.

Smarter design in a bull-nose bumper.

7-gauge bull-nose bumper not only protects against frontal impacts, but also contains an integral underskirt to minimize blowout of debris and dust. The bottom, leading edge of the deck is raised 1/4", allowing grass to stand more upright when entering the cutting chamber, ensuring a level cut. Leaf "plowing" during spring and fall clean-up also is significantly reduced.

Convenience and Comfort

Operator controls are conveniently located. Large 1-5/8" diameter steering levers increase comfort and reduce fatigue. Handy storage compartment provides location for cell phone, tools, and more. Built-in cup holder provided.

7-gauge, high-strength steel

Constructed of high-strength 7-gauge steel (50,000 psi minimum yield strength), the deck shell is extremely resistant to impacts and abrasion. At a full 5-1/2" deep, the TURBO FORCE deck has more than enough capacity to handle the most demanding conditions.

*Comparison based on 7-gauge high-strength steel versus 10-gauge steel

High-performance Discharge Chute

High performance 5/16" rubber discharge chute allows for close trimming without damaging chute or landscape structures. Patented design provides excptional clipping dispersion.

Powerful Engines

The Kubota® 23 hp liquid-cooled diesel engines are geared for high torque while also delivering fast 11.2 mph ground speeds. The powerful, yet fuel-efficient engines come in a compact package that is exceptionally well balanced for low vibration. The liquid-cooled system ensures cleaner combustion and extended engine life.

Folding Rollover Protection System ROPS

A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, such as loading on an enclosed trailer, the ROPS can be temporarily unlocked and folded down.

The industry's toughest spindle assembly

Rigorously tested to ensure it can survive impacts that would destroy lesser spindles. The cast iron housing, with a massive 9-3/8" diameter base, absorbs impact loads and distributes them across a broader area of the robust deck shell. Tapered roller bearings last up to six times longer than ball bearings.

Comprehensive Warranty*

1 year Limited; 2 year Engine, Hydraulics, Electric Clutch & Deck Shell; 3 year Spindle Assembly.**

**Third year parts only.

Exclusive TURBO FORCE® Deck

High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patent-pending adjustable discharge baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.
